Applicable Water

Tap water

Water Temperature

1°C-70°C

Ambient Temperature

1°C-50°C

Working Water Pressure

0.05MPa-0.8MPa

Effluent Flow

Flow rate (sensor):2.5L/min; Flow rate:(Manual):3.5L/min (dynamic pressure 0.1MPa)

Rated Voltage

DC6V

Standby Power

DC standby power consumption ≤ 0.2mW; AC standby power consumption ≤ 2mW

Power Supply

AAx4 Battery/ Power Adapter: input AC220V,output DC6V

Induction Mode

Infrared Induction

Sensing Distance

Open when sensed, close when sensed again( the sensor distance is 10±1
cm by 30*30cm white board, and less than 7cm by hand)

Low Battery

1.When the battery voltage is close to 5v ± 0.1 V, (the lamp ring flashes quickly for reminding, the sensor still can work normally) ;
2.When the battery voltage is lower than 4.8 v ± 0.1 V (the lamp ring flashes
quickly for alarming, induction does not work)

Valve Closing When Power Off

Sensor can self-closing valve in case of power failure when valve opening.

Automatic water cutoff in case of timeout

Hand or obstacle entering the sensing area, water valve open. Remove hand or
obstacle, the valve keep open.
If hand or obstacle is sensed again within 90 seconds , the valve closed. If there
is no further sensing within 90 seconds, valve automatic closed.
The blue indicator light rings on for 1 second before turning off during induction,
with a time tolerance of ± 10%.
